Founded in 1976, Lane Tool & Mfg. Co. has been a leader in the industry for over 40 years. With a focus on building progressive, draw and specialty dies, we are known for our work on complex designs and intricate builds. We are also a supplier of can tooling and equipment to metal packaging companies worldwide.
With a focus on building progressive, draw & specialty dies, we are known for our work on complex designs and intricate builds. We recognize the intent of the design is what makes a production tool valuable, which is why we continue to have success in our field. With a fully equipped 20,000 sq. ft. tool room, 400-ton and 80-ton tryout presses, our highly skilled tool & die makers produce tooling that is accurate, precise and profitable for its lifetime.
Our In-House Design and Engineering department utilizes the following software: SolidWorks, LogoPress, AutoCAD, DieMaker & Microsoft Project.
Lane Tool is a valued worldwide supplier of can tooling and equipment for the metal packaging industry; including tab, shell, lane, score, double, aerosol and most other metal packaging tooling. Our team consists of highly qualified engineers and technicians that design, build, and service equipment and tooling for this unique industry. We design and build systems specific to your needs and requirements, paying special attention to value, quality, and turnaround time.
Nine vertical machining centers with ranges up to 84x40x30 to meet all your machining requirements, including 2, 3, and 4 axis, as well as a High Speed machining center up to 20,000 RPM. Two Mazak CNC turning centers, including one large capacity NEXUS 400-IIM, 27” diameter x 40” long with a 4-5/8 bar capacity and Y-axis (Live-Tooling) for a variety of machining such as face and o.d. drilling, keyway finishing and milling.
Our 4-axis SUPREMA WATERJET, powered by Mitsubishi Electric, will cut virtually any material up to a 6" thickness. With INTELLIGENT TAPER CONTROL the need to reduce production speed is eliminated.
Machine Travels: 120x60x6
Wire EDM: One Mitsubishi MV 2400S, one Sodick AG600L and two Sodick AQ535L machines with travel up to 20 x 13 x 10-5/8 for the accuracy you require.
Conventional EDM: Three Mitsubishi EA8M
Accuracy is not only a key aspect in tooling, it is the most important aspect. Our dedicated, highly skilled professionals do not take their job lightly; with our technologically advanced inspection and quality control equipment they ensure everything we produce is precisely how it should be.
As you can imagine, after 40 years in business we have a lot of projects under our belt . Please take a look at some of the great projects we have had the pleasure of working on.
Our 20,000 square foot, free-standing facility is conveniently located in South Elgin. We are equipped with 400-ton and 80-ton tryout presses, complete CNC and EDM departments, a comprehensive tool room, an in-house design and engineering department and precision inspection capabilities. [Complete Facility List: CLICK HERE]
